Model

Parameter

Item

XBJ-6

XBJ-9

XBJ-12

XBJ-15

Plate thickness for milling  (mm)

6-50

Max. milling depth for one time (mm)

4

Milling angle of tool tip

   0°~45°

Effective milling length  (m)

6

9

12

15

Rotate speed of milling tip (rpm)

80-400(8 rank exchange rack)

Feed rate of milling  (m/min)

0.25-0.6

Fast forward speed (m/min)

2

Main milling power  (kw)

5.5

Quantity of hydraulic cylinder

9

13

17

21

Operation pressure of hydraulic system  (Mpa)

2.5

Total power  (kw)

12.7

9

9

9

Outline dimension (length*width*height)  (m)

8.7×2×2.2

11.7×2×

2.4

14.7×2×

2.4

17.7×2.1×2.6

Weight  (t)

12

16

18

24

Operating temprature

            -20℃≤t≥45℃

Operating conditions

The machine should not be used in out of doors.
