The main technical parameters
Model | SBZJ12 |
Applicable work-piece dimension | 300-1200mm 1500 |
Applicable work-piece length | 4000-15000mm |
Maximum load ing capacity | 20T |
Hydraulic system pressure | 14Mpa |
Left and right oil cylinder maximum pressure | 15T |
Up and down oil cylinder maximum pressure | 15T |
Left and right oil cylinder maximum stroke | 550mm |
Up and down oil cylinder maximum stroke | 900mm |
Active roller way (m) | 4 sections (2 sections with motor, 2 sections with chain and wheel) |
Idle roller way (m) | 2 sections |
Rail | 20m each side, 38kg/m |
Oil pump motor power | 11KW |
Roller way motor power | 2.2KW × 2 |
Walking motor power | 1.1kw×2 |
