Model | LHZ4×4 | LHZ5×5 | LHW6×6 | LHW7×7 | |
Lifting stroke mm | 4000 | 5000 | 6000 | 7000 | |
Retracting stroke mm | 4000 | 5000 | 6000 | 7000 | |
Lifting speed mm/min | 1000 | ||||
Retracting speed mm/min | 120-1200 | ||||
Minimum distance between boom and track surface mm | 110/950 Movable with rotation/stationary with rotation | 1180/1170 Movable with rotation /stationary with rotation | |||
Boom end maximum loading kg | 120 | 200 | |||
Column revolving | angle | ±180° | |||
Speed rpm | 0.36rmp/or by manual | ||||
Trolley traveling mm/min | 1700 | 2500 | |||
Inner span of trolley rail mm | 1730 | 2000 | 2000 |
