Model | HB1 | HB3 | HB6 | HB12 | HB20 | HB30 |
Related loading kg | 100 | 300 | 600 | 1200 | 2000 | 3000 |
Revolve speed rpm | 0.1-1 | 0.2-2 | 0.1-1.1 | 0.1-1 | 0.09-0.9 | 0.08-0.8 |
Tilt speed rpm | 2 | ≈0.9 | ≈0.8 | ≈0.5 | ≈0.4 | ≈0.3 |
Work-table dia mm | 400 | 600 | 800 | 1000 | 1200 | 1400 |
Max eccentricity distance mm | 100 | 150 | 150 | 200 | 250 | 250 |
Max gravity center distance mm | 150 | 200 | 250 | 250 | 300 | 400 |
Work-table tilting angle | 0-120 | 0-120 | 0-120 | 0-120 | 0-120 | 0-120 |
Revolve motor power kW | 0.06 | 0.37 | 0.37 | 0.75 | 1.1 | 1.5 |
Tilting motor power kW | 0.18 | 0.37 | 0.55 | 1.1 | 1.5 | 2.2 |
Revolve dia.at 90° mm | ≤600 | ≤1000 | ≤1500 | ≤1500 | ≤2000 | ≤2300 |
Equipment weight kg | 70 | 260 | 700 | 1000 | 2000 | 3350 |
speed adjusting way | Rotation speed VFD control | |||||
Model | HB50 | HB80 | HB100 | HB150 | HB200 | HB300 | HB500 |
Related loading kg | 5000 | 8000 | 10000 | 15000 | 20000 | 30000 | 50000 |
Revolve speed rpm | 0.07-0.7 | 0.06-0.6 | 0.06-0.6 | 0.05-0.5 | 0.05-0.5 | 0.04-0.4 | 0.04-0.4 |
Tilt speed rpm | ≈0.2 | ≈0.14 | ≈0.14 | ≈0.14 | ≈0.14 | ≈0.10 | ≈0.10 |
Work-table dia mm | 1600 | 2000 | 2000 | 2200 | 2500 | 3000 | 4000 |
Max eccentricity distance mm | 250 | 200 | 200 | 200 | 200 | 200 | 200 |
Max gravity center distance mm | 400 | 400 | 400 | 500 | 630 | 630 | 800 |
Work-table tilting angle | 0-120 | 0-120 | 0-120 | 0-120 | 0-120 | 0-120 | 0-120 |
Revolve motor power kW | 1.5 | 2.2 | 3 | 3 | 4 | 7.5 | 11 |
Tilting motor power kW | 3 | 4 | 4 | 5.5 | 7.5 | 11 | 18.5 |
Revolve dia.at 90° mm | ≤2800 | ≤3200 | ≤3200 | ≤3400 | ≤3400 | ≤4200 | ≤5700 |
Equipment weight kg | 4300 | 8000 | 8200 | 14000 | 17000 | 20000 | 27000 |
speed adjusting way | Rotation speed VFD control | ||||||
